额定电压Rated Voltage

1000VDC

安全等级Protection Class

Class Ⅱ

防护等级Protection Degree

IP65

防火等级Flame Class

UL94-V0

温度范围Temperature Range

-40℃~+85℃

连接电缆Connecting Cable

2×0.3-1.5mm²

防水结构Waterproofing structure

灌胶   Glue sealing

汇流带宽度Width Of Copper Ribbon

最大6mm  Up to 6mm

连接方式Connection Method

焊接Soldering

绝缘材料Insulation Material

PPO  （or ABS/PC）

导体材料Contact Material

铜合金镀锡Copper alloy, tin plated

外形尺寸Overall Dimension

65×50 ×16.5mm

粘接方式 Bonding mode

硅胶   silica gel

粘接面积 The bonding area

1500mm²

连接器 Connector

No
